Aten CC2000-XL Control Center Extra Lite 1master up to 64 Nodes Management Software

Overview

ATEN's CC2000 Management Software - updated with new, powerful, features including VMware support - provides IT administrators with the tools they need to access and control their entire distributed data center environment. Offering convenient, economical, centralized management of all their IT devices, the CC2000 Management Software puts administrators in complete control of their remote data centers and branch offices no matter where in the world they are deployed. The CC2000 patented Panel DynaArray mode lets administrators view the output of multiple ports in individual panels on the same screen. Under this mode, the video output of each selected device displayed in its own panel on the screen. To access and manage the device, simply move the mouse pointer over its panel and click.

Powerful Security

Powerful security features include both internal and external authentication - external authentication support includes LDAP, LDAPS, Kerberos, Active Directory, RADIUS, TACACS+, and NT Domain Option to force users of all CC-managed devices to be authenticated through the CC - users cannot log in to the devices directly Compliant with the x.509 Digital Certificate Standard Supports SSL 128-bit data encryption and RSA 1024-bit certificates to secure users log in from the browser Flexible session time-outs Configurable user and group permissions for server access and control Supports strong password protection, SAS 70 compliance for a configurable amount of failed login attempts and user ID lock out parameters Devices can identify themselves by Name, MAC address or IP in the browser

Specifications

Model Number:  CC2000-XL

Brand:  Aten

Alt Part Number(s):  CC2000-XL

Product Type:  Management Software



Technical Description

Brand:   Aten

Model:  CC2000-XL

Service processor:

Dell iDRAC5/6/8,

IBM RSA II, HP iLO2/3/5 Dell CMC,

IBM AMM, HP OA, IPMI,

Network Protocol & IP Tools:

IPv4/IPv6, RDP, VNC,

SSH, and Telnet.

Logs:

System logs.

Device logs. Serial

console server logs.

SNMP traps. Activity report.

Viewer

Java Client (JNLP).

Win Client (ActiveX).

Mouse DynaSync.

Panel array mode (up to 64 KVM ports).

Virtual media.

Notification SMTP.

SNMP (v1, v2c, v3). Syslog.

System message.

Task scheduling

CC2000 database backup.

CC2000 configuration backup.

Device firmware upgrade.

Export system logs.

Export device logs.

Export serial console server logs.

Power on/off control on ATEN PDU.

Security

AES 256-bit encryption for secure end-to-end node access.

IP or MAC addresses blocking.

Virtual media security blocking.

Configurable failed login attempts and lockout.

Support certificate signed by third-party authorities (CA).

Secure web connection with TLS v1.2 and RSA 2048-bit certificates.

Strong user password authentication.

Configurable user session timeout.

Features:

Access control to grant or restrict user access by IP or MAC address, and SAS 70 compliance for configurable failed login attempts and lockout Supports certificates signed from third-party authorities (CA) TLS v1.2 data encryption and RSA 2048-bit certificates to secure user logins from a browser

strong user password policy to enhance the security of user accounts

Consolidates logs from ATEN’s KVM over IP switches, serial console servers, and other devices through syslog protocol for audit trail

Message Box — shows internal system messages or critical logs that can be viewed in full detail with just one simple click.

Panel Array Mode – allows administrators to monitor multiple video outputs of remote servers in one screen Mouse DynaSync – automatically synchronizes the local and remote mouse cursors

Delivers server redundancy through primary/secondary architecture for service availability Add specific devices and ports to My Favorites for quick access
